Circular saws
SOCO FA111DR circular saw
203 283,15 zł net
No rating
12 months of warranty
Contact with a trader:
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
Krzysztof Penkowski
E-mail: krzysztof.penkowski@eurometal.com.pl
Telefon: 603 400 333
The SOCO FA111DR circular saw is an automatic machine with the ability to cut only at a right angle. This machine can be equipped with hydraulic or servomotor feeding. The NC-SN series of machines is intended for those customers who count the cost of material. Thanks to the patented clamping and feeding system, waste has been minimized to 20 mm. This is a worldwide patent of SOCO.
Quantity
Add to cart
Circular saws are used to cut pipes and profiles as well as solid materials. The SOCO FA111DR disc cutter is an automatic machine with the ability to cut only at a right angle. This machine can be equipped with hydraulic or servomotor feeding. The NC-SN series of machines is intended for those customers who count the cost of material. Thanks to the patented clamping and feeding system, waste has been minimized to 20 mm. This is a worldwide patent of SOCO.
For cutting lengths above 500 mm we recommend purchasing a roller feeder from the receiving side RTO (+) for using TCT discs, SOCO asks for sending the cutting specification.
Standard equipment:
- Digital readout for cutting length setting and programmable automatic counter of cut parts
- Cutting disc speed control inverter
- Information displayed on the control panel to eliminate inconveniences
- Automatic hydraulic system
- 3-fold feeding
- Patented cutting head gear
- Sliding vertical cutting head ensures stable and precise cutting
- Device for eliminating play on the cutting disc improving the life of the disc
- Patented feeding system with precise feed and stable clamp
- Automatic lubrication system
- Efficient circulating cooling system improves cutting quality and extends the life of the disc
- Safety guards
Control:
- Intuitive and operator-friendly programmer with touch screen
- Possibility to program different lengths on one workpiece
- Possibility to save multiple programs
Optional equipment:
- roller conveyor on the feeding side
- roller conveyor on the receiving side
- bumper with measure
- jaws in V-shape
| Technical data | Unit | Value |
|---|---|---|
| The diameter of the cutting disc | [mm] | 370 |
| Vise opening width | [mm] | 114 |
| Total power | [kW] | 6,4 |
| Cutting angle | [°] | 90 |
| Pipe | [mm] | 114 |
| Profile | [mm] | 110 - 110 |
| Roller | [mm] | 75 |
| Square bar | [mm] | 70 - 70 |
| Tube / roller packages | [-] | Opcjonalne szczęki typu V Max 9 sztuk (w zależności od średnicy |
| HP main motor / pole | [HP] | 5/4 |
| Roller speed | [60Hz] | 22-108 |
| HSS blade size mm | [mm] | 250 - 370 |
| TCT blade dimension (+) | [-] | 285 - 360 |
| Feed | [-] | standard: 10–600 mm x 1-3 razy (maks. 1800mm); wydłużona: 10–1000 mm x 1-3 razy (maks. 3000 mm) |
| Cooling system | [-] | 1/4HP, pompa wodna z obiegiem zamkniętym |
| Hydraulic system | [-] | 3HP -4P ciśnienie obróbcze 35 kg/cm2 |
| Dimensions | [mm] | 2310x1100x1850 |
| Weight | [kg] | 1560 |
